Motan Condens Plus 100 25kW Condensing Wall Hung Gas Boiler

• 5-YEAR WARRANTY
• HIGH-TECH design – glass front panel (touch screen) with a 4,3-inch screen (visible area);
• Up to 106% efficiency and modulation ratio 1:10;
• Available in 25, 29, 35 kW variants, respectively;
• Eco-friendly – during operation it emits significantly reduced amounts of NOx, CO and CO2 – NOx 5 Class;
• Increased comfort on the Domestic Hot Water circuit – OVERSIZED secondary heat exchanger;
• Designed and built for maximum operational efficiency and savings, according to the latest European legislative requirements;
• STAINLESS STEEL main heat exchanger;
• The possibility to connect a chrono - thermostat and/or an external temperature probe;

Technical specifications

Product type	Condensation
Energy efficiency (Directive 92/42 / EEC)	★★★★
Nox Class	5
Seasonal energy efficiency class for indoor heating	A
Maximum rated power (80 / 60ºC) (G20-I2H)	25,6 kW
Maximum rated power (50 / 30ºC - condensation) (G20-I2H)	28,2 kW
Thermal efficiency at rated calorific value (80 / 60ºC)	97%
Thermal efficiency at rated calorific value (50 / 30ºC)	106%
Domestic hot water flow at ∆T = 30 ° C	13.5 l/min
ACM comfort according to EN13203	★★★
DHW energy efficiency class	A, XL load profile
